China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine

جزئیات محصول

محل منبع: چین

نام تجاری: Beyde

گواهی: CE

شماره مدل: 500/1+6

شرایط پرداخت و حمل و نقل

مقدار حداقل تعداد سفارش: 1 ست

جزئیات بسته بندی: بسته بندی کانتینر ایمنی

زمان تحویل: 90 روز

شرایط پرداخت: L/C ، D/A ، D/P ، T/T

قابلیت ارائه: 200 مجموعه در سال

بهترین قیمت رو بدست بیار
جزئیات محصول
برجسته کردن:

500mm tubular stranding machine,big bearing tubular stranding machine,China manufacture tubular stranding machine

,

big bearing tubular stranding machine

,

China manufacture tubular stranding machine

استفاده:
رشته
رنگ:
با توجه به نیاز مشتری
نام:
ماشین رشته لوله ای
کاربرد:
فولاد ، آلومینیوم ، سیم فولادی
ماده سمی:
فولاد، مس
ماسوره پرداخت مرکزی:
PN400-PN630
اندازه ماسوره برداشت:
PND800-PND1600
حداکثر قطر سیم لخت:
4 میلی متر
ضمانت:
12 ماه
استفاده:
رشته
رنگ:
با توجه به نیاز مشتری
نام:
ماشین رشته لوله ای
کاربرد:
فولاد ، آلومینیوم ، سیم فولادی
ماده سمی:
فولاد، مس
ماسوره پرداخت مرکزی:
PN400-PN630
اندازه ماسوره برداشت:
PND800-PND1600
حداکثر قطر سیم لخت:
4 میلی متر
ضمانت:
12 ماه
توضیحات محصول



China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine



This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.

Application:
This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.
Component:
Central pay-off. cage host,taping device (optional),capstan,take-up and traverse device,and electric control system.



Model 400 500 630
Inlet wire Dia.(mm) Conductor 1.5-3.5 1.8-4.0 2.0-5.0
Steel 1.0-2.5 1.5-3.0 1.8-4.0
Cores 1.2-3.5 1.5-5.0
Frame rotation speed(r/min) 700 600 400
Stranding Pitch(mm) 41-312 44-334
Linear Speed(m/min) 27-205.3 22-166.85 14-108.9
Capstan Dia.(mm) 800+1000 1000+1200 1000+1250
Size of tak-up bobbin PN1250 PN1600 PN1600



China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine 0

China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine 1

FAQ
1.Q: Where is your factory located? A: Our factory is located in HEJIAN CITY, HEBEI PROVINCE, CHINA,
we are near Beijing, Tianjin and Shijiazhuang air port, and CANGZHOU WEST high-speed railway station.
2.Q: What is the advantage about your company? A: Our company has skilled technical engineer and workers and professional production line.
3.Q: Why should l choose your products? A: We are direct manufacturer, we can ensure the stable product quality and provide in time service.
4.Q: The logo and the color can be customized? A: Yes
5.Q:What's your near sea loading port: Tianjin port
